KitchenAid Fault Codes

Usually failure codes are caused by a faulty timer (aka ERC – the Electronic Range Control). Sometimes, even when the failure code implies that another component has failed, this can actually be a timer problem (whereby the timer is not displaying the correct fault code). If you are not sure whether the code you are seeing is due to a problem with the timer please call us, or send us an email, since we can help you determine whether the failure code is likely a timer problem or a problem with some other component. We can repair most timers so if you are sure your problem pertains to the timer (or ERC) please fill out a repair service request or call us  (647) 483-9051.

Kitchen Aid Range  /  Stove  /  Oven Fault Codes
Failure CodeFault Code DescriptionSolution
4 Digit Failure Codes (for 2 digit codes see below)
F1 – E0EEPROM communication error1. Disconnect power for at least 30 seconds.
2. Re-apply power and observe for at least one minute.
3. If code re-appears, replace control board (also called ERC or clock). Note: Applies to all F1-E… codes except F1-E3.
F1 – E1EEPROM checksum error
F1 – E2UL A/D error(s)
F1 – E4Model ID error
F1 – E5Calibration shifted
F1 – E6Latch signal mismatch error
F1 – E9Stack overflow
F1 – E3Wiring harness cavity size does not match previously stored valueThe “Cavity Size Select” jumpers in the wiring harness indicate a cavity size different from that which the control was previously configured for. Check the jumpers in the harness to make sure they agree with the actual oven size.

F2 – E0Shorted keypad (also called touch pad)1. Check keypad connector for firm connection (keypad connects to control board).
2. Press CANCEL. If error code returns after 60 seconds, replace keypad (also called touch pad or membrane switch). Some models incorporate keypad in to control board as one unit. In this case, replace control board (also called ERC or clock).
F2 – E1Keypad cable unplugged
F2 – E5Cancel key drive line open
F2 – E6Cancel key drive line open
F3 – E0Oven temperature sensor (RTD) opened (upper oven, if double oven)Replace Oven temperature sensor (RTD)

Note: Applies to all F3-E… codes.

F3 – E1Oven temperature sensor (RTD) shorted (upper oven, if double oven)
F3 – E2Oven temperature is too high (Cook mode)
F3 – E3Oven temperature is too high (Clean mode)
F3 – E4Oven temperature sensor (RTD) opened (lower oven, if double oven)
F3 – E5Oven temperature sensor (RTD) shorted (lower oven, if double oven)
F3 – E6Warming drawer sensor open
F3 – E7Warming drawer sensor shorted
F4 – E1Meat probe malfunction – shortedProblem could be with the probe, the receptacle, or probe circuit. Check probe. Look for pinched wire. Look for condensation or contamination on probe receptacle. Replace probe if all else checks out ok.
F5 – E0Door switches do not agree (condition exists when door switch is closed indicating an open door, and latch switch is closed indicating a locked door)1. If door latched:
A.     Disconnect power from unit.B.     Check wires and connectors from control to door switch, then from door switch to control. If no damage to wires and all connectors okay, proceed to step C.C.      Replace door switch.D.     Re-apply power.E.      Press and hold any key down for 1 minute to clear F5 failure code from memory. F2 will appear. Press CANCEL and observe for 1 minute to ensure operation is correct.

2. If door not latched:

A.     Disconnect power from unit.

B.     Check wires and connectors from control to latch switch, then from latch switch to control. If no damage to wires and all connectors okay, proceed to step C.

C.      Repeat steps A and B for door switch.

3. Measure door switch (door open = switch open small low voltage terminals). Replace switch if defective.
4. Measure latch switch (unlatch = switch open, CAUTION – oven light contacts are closed). Replace switch if defective.
5. If corrections are made in any step, reconnect power to control. Press and hold any key for 1 minute to clear R failure code from memory. F2 will appear. Press CANCEL and observe for 1 minute to ensure operation is correct.
6. If failure remains, disconnect power and replace control.

Note: Applies to all F5-E… codes.


F5 – E1Self clean latch will not lock
F5 – E2Latch during CLEAN error
F5 – E5Self clean temperature not reached within 45 minutes.
F5 – E6Door is open, but latch is locked
F5 – E7Self clean latch will not unlock
F6 – E0Return line not connectedIf switch pulse return line is not connected, electronic control will display F6 within 60 seconds after power up. Replace control.
F7 – E1Common switch wire is defectiveCommon wire (+5VDC) to latch switch, and to door switch is shorted to chassis ground or neutral. A double oven will have two of each switch and one common wire.
1. Check connections at control and at the latch switch and door switch.
2. If all connections are good, then check the individual switches as outlined for the F5 failure.

2 Digit Failure Codes
F0Board failureReplace control board (also called ERC or clock).
F1Board failureReplace control board (also called ERC or clock).
F2Oven temperature is too high1. Look for welded relay contacts on bake or broil relays. If this happens, replace oven control (also called clock or ERC).
2. For SELF CLEAN models: check door lock operation.
3. Look for a high resistance connection or any other cause of high resistance in the oven temperature sensor circuit. Check sensor, sensor harness and sensor harness connection at sensor and oven control. Replace sensor if found defective. Remember: Oven control (ERC) measures resistance of sensor circuit, not actual oven temperature.

F3Oven temperature sensor (RTD) openReplace Oven temperature sensor (RTD)
F4Oven temperature sensor (RTD) shortedReplace Oven temperature sensor (RTD)
F5Board failureReplace control board (also called ERC or clock).
F7Function key stuck on ERCReplace control board (also called ERC or clock).
F8Board failureReplace control board (also called ERC or clock).
F9Oven door lock failureCheck wiring to door lock switch (the wire harness may be connected wrong). Check for stuck lock switch.




Kitchen Aid Built-In Microwave Oven Fault Codes
Failure CodeFault Code DescriptionSolution
F1 – E3
or
F1 – E4
Electronic control malfunctionReplace control.
F2 – E0
or
F2 – E1
Keypad not connectedCheck keypad connector for firm connection.
F2 – E3Keypad held down too long, or keypad is shorted.Press CANCEL, if error code returns after 60 seconds, replace keypad (also called touch pad or membrane switch).



Kitchen Aid Cooktop Fault Codes
Electronic Touch Ceramic 30 inch. Cooktop KECC508MBL
Failure IndicationFailure CodeFault Code DescriptionSolution
 F03One or more keys permanently pressed1. Clean the glass surface and remove all objects placed on it.
2. If failure remains, disconnect power for 1 minute.
3. Reconnect power.
4. If failure remains, replace the touch control module.
 F12Electronic board and touch module communication error1. Disconnect power for 1 minute.
2. Reconnect power.
3. If failure remains, replace board connection cable between touch control module and electronic control.
4. If failure remains, replace the electronic control.
5. If failure remains, replace the touch control module.
 F13Internal CPU checksum errors1. Disconnect power for 1 minute.
2. Reconnect power.
3. If failure remains, replace the touch control module.
 F22Key sensitivity problem1. Disconnect power for 1 minute.
2. Reconnect power.
3. If failure remains, replace the touch control module.
 F36Temperature probe hardware error1. Disconnect power for 1 minute.
2. Reconnect power.
3. If failure remains, replace the touch control module.
OVER TEMPERATURE INDICATION
 Three indicators alternatively blink in left and right sideThis is a temporary standby condition to prevent over temperatures in the cooktop.
Let the cooktop cool down and the blinking indicators will stop.
Electronic Touch Ceramic 36 inch. Cooktop KECC568MBL
Failure IndicationFailure CodeFault Code DescriptionSolution
 F03One or more keys permanently pressed1. Clean the glass surface and remove all objects placed on it.
2. If failure remains, disconnect power for 1 minute.
3. Reconnect power.
4. If failure remains, replace the touch control module.
 F12Electronic board and touch module communication error1. Disconnect power for 1 minute.
2. Reconnect power.
3. If failure remains, replace board connection cable between touch control module and electronic control.
4. If failure remains, replace the electronic control.
5. If failure remains, replace the touch control module.
 F13Internal CPU checksum errors1. Disconnect power for 1 minute.
2. Reconnect power.
3. If failure remains, replace the touch control module.
 F22Key sensitivity problem1. Disconnect power for 1 minute.
2. Reconnect power.
3. If failure remains, replace the touch control module.
 F36Temperature probe hardware error1. Disconnect power for 1 minute.
2. Reconnect power.
3. If failure remains, replace the touch control module.
OVER TEMPERATURE INDICATION
 Three indicators alternatively blink in left and right sideThis is a temporary standby condition to prevent over temperatures in the cooktop.
Let the cooktop cool down and the blinking indicators will stop.



Kitchen Aid Front Loading Automatic Washer Fault Codes (Model KHWS01PMT/ WH)
Failure CodeFault Code DescriptionSolution
FHNo water detected entering machine or pressure switch trip not detectedIf after 30 seconds the control does not detect water entering machine, the valves will be turned off and the error code will be displayed.
OR
If the control has turned the water valves on, and after 8 minutes, the flow sensor has detected 10.5 gallons of water passing through it, but has not detected the pressure switch trip, the valves will be turned off, and the error code will flash.
Press PAUSE/CANCEL twice to clear the display.

Possible Causes / Procedure

•  If there is no water in the unit:
– Make sure that both valves at the water source(s) are turned on all the way.
– Check for plugged or kinked inlet hoses or plugged screens in the inlet valves.
– Verify inlet valve operation. •  If there is water in the unit:
– Verify drain pump operation.
– Verify that the pressure switch hose is in good condition and properly connected to tub
and pressure switch. 1. Verify there is not a siphon problem.
2. Unplug washer or disconnect power.
3. Verify wire harness connections to inlet valves, pressure switch, drain pump, flow meter,
and Central Control Unit (CCU).
4. Check all hoses for possible leaks.
5. Plug in washer or reconnect power.
6. Verify pressure switch operation.
7. Verify flow meter operation by blowing air through the part and measuring the resistance.
8. Verify CCU operation by running a Diagnostic test or any cycle. Replace failed component.

F02Long drainIf the drain time exceeds eight minutes, the water valves are turned off and “F02” is flashed.

Press PAUSE/CANCEL two times to clear the display.

NOTE: After four minutes the “Sud” error will be displayed, then four minutes later the “F02” error code will be displayed..

Possible Causes / Procedure

1. Check the drain hose and make sure it is not plugged or kinked.
2. Unplug washer or disconnect power.
3. Check the electrical connections at the pump and make sure the pump is running.
4. Check the drain pump filter for foreign objects.
5. Plug in washer or reconnect power.
6. If the above does not correct the problem, go to step 7.
7. Unplug washer or disconnect power.
8. Replace the pump.


F05Water temperature sensor errorIf during the water heating step in the wash cycle, the water temperature sensor (NTC) value is out of range, the “F05” error code will be displayed.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check the water temperature sensor. Check connections to the water temperature sensor.
3. Check resistance of heating element, if present on this model. (abnormal = infinity).

Replace failed component.


F06Drive motor tachometer errorThe control is unable to properly detect motor speed and the machine will shut down. If a failure occurs during high-speed spin, the door will be unlocked after three minutes.

Possible Causes / Procedure

1. Verify the shipping system including shipping bolts, spacers and cables are removed.
2. Unplug washer or disconnect power.
3. Check wire harness connections between the drive motor and the Motor Control Unit (MCU), and between the MCU and the Central Control Unit (CCU).
4. Plug in washer or reconnect power.
5. Check the MCU by looking for operations of the drive motor.
6. Check the drive motor for powered rotations.

Replace failed component.


F07Motor control unit errorThe main control has detected a short in the Motor Control Unit. If a failure occurs during high-speed spin, the door will be unlocked after three minutes.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check wire harness connections between the drive motor and the Motor Control Unit (MCU), and between the MCU and the Central Control Unit (CCU).
3. Plug in washer or reconnect power.
4. Check the MCU by looking for operations of the drive motor.
5. Check the drive motor for powered rotations.

Replace failed component.


F09Overflow conditionIf the overflow contact on the pressure switch is closed for more than 60 seconds, an Overflow Condition will occur. In an overflow condition, the door remains locked and the drain pump runs constantly, even if PAUSE/CANCEL is pressed twice and the display is cleared. Turn off hot and cold water faucets and unplug the unit before servicing.

Possible Causes / Procedure

1. Check the drain hose and make sure it is not plugged or kinked.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the drain pump, pressure switch, and Central Control Unit (CCU).
4. Check/clean drain pump filter of foreign objects.
5. Check for drain pump failure.
6. Check the inlet valve for proper shut off.
7. Check the pressure switch for proper operation.

Replace failed component.


F10Motor control unit (MCU) heat sink thermal tripIf the thermal protector on the MCU heat sink gets too hot, it will open the thermal protector on the heat sink which will stop motor functions and an “F10” will be displayed.

Possible Causes / Procedure

1. Check for proper installation, verify the unit is not located near a source of heat and has proper ventilation.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the MCU, the motor, and Central Control Unit (CCU).
4. Check the drive system for any worn or failed components.
5. Plug in washer or reconnect power.
6. Check the MCU by looking for operations of the drive motor.
7. Check the drive motor for powered rotations.

Replace failed component.


F11Serial communication errorCommunication between the Central Control Unit (CCU) and the Motor Control Unit (MCU) cannot be sent correctly.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check wire harness connections to the MCU, the motor, and Central Control Unit (CCU).
3. Check the drive system for any worn or failed components.
4. Plug in washer or reconnect power.
5. Verify CCU operation by running a Diagnostic test or any cycle.
6. Check the MCU by looking for operations of the drive motor.
7. Check the drive motor for powered rotations.
8. Check that the serial harness at the MCU is not mounted upside down. The wires should be to the left when facing the MCU connectors.

Replace failed component.


F13Dispenser circuit errorIf the dispenser motor is not able to be driven to its proper position.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check mechanical linkage from dispenser motor to the top of the dispenser.
3. Check wire harness connections to the dispenser motor and Central Control Unit (CCU).
4. Check dispenser motor for powered rotations.

Replace failed component.


F14EEPROM errorThe Central Control Unit (CCU) receives its data from an EEPROM onboard the CCU. If there is an error reading this data it will cause this error.

Possible Causes / Procedure

A power glitch may cause this error.
1. Unplug washer or disconnect power for two minutes.
2. Verify CCU operation by running a Diagnostic test or any cycle. Replace if defective.


F15Motor control unit (MCU) errorIf the MCU detects multiple resets or errors during a wash cycle it will go into this error mode.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check wire harness connections to the MCU, the motor, and Central Control Unit (CCU).
3. Check drive belt.
4. Plug in washer or reconnect power.
5. Check the MCU by looking for operations of the drive motor.
6. Check the drive motor for powered rotations.

Replace failed component.


F21
or
F22
CCU / Touchpad / LED assembly errorThis error occurs if the touchpad/LED assembly is not able to transmit/receive data to/from the central control unit (CCU).

Possible Causes / Procedure

1. Check the touchpad/LED assembly by selecting different cycles and changing the modifiers and options available to confirm the touchpad/LED is responding.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the touchpad/LED assembly and Central Control Unit (CCU).

Replace failed component.


FdUDoor unlock errorA Door Unlock Error occurs if the door cannot be unlocked. It will try to unlock the door six times before displaying the error code.

Possible Causes / Procedure

• Door lock mechanism is broken.
• Door switch/lock unit failure.
1. Check door switch/lock unit for foreign objects.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the door switch/lock unit and Central Control Unit (CCU).

NOTE: The door switch/lock unit can be manually unlocked:

To manually unlock the door lock system, perform the following steps.
1. Unplug the power cord from the outlet.
2. Remove the lower toe panel.
3. Reach up along the inside of the front panel and locate the bottom of the door latch assembly.
4. Located on the bottom of the door latch assembly is a teardrop shaped tab. Gently pull the tab down approximately 1/4 inch, or until a click is heard.
5. The door may now be manually opened.


FdLDoor lock errorA Door Lock Error occurs if the door cannot be locked. It will try to lock it six times before displaying the error code.

Possible Causes / Procedure

• Door lock mechanism is broken or removed from door.
• Door switch/lock unit failure.
1. Unplug washer or disconnect power.
2. Check door switch/lock unit.
3. Check the wire harness connections to the door switch/lock unit and Central Control Unit (CCU).


SudSuds lock (Overdose of detergent detected during the wash cycle)The Motor Control Unit senses a suds lock condition by analyzing the current draw on the drive motor. If “Sud” is displayed a potential Suds Lock is detected. This may signify a bad pump, an extra heavy load, excessive detergent, or excessive suds.

Possible Causes / Procedure

• If too much detergent was used:
– Run the unit through a Rinse/Spin cycle.
– Run a Normal cycle without adding any detergent.

This should clear the unit of the excess detergent.

1. Check the drain hose and make sure it is not plugged or kinked.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the drain pump, pressure switch, and Central Control Unit (CCU).
4. Check/clean drain pump filter of foreign objects.
5. Plug in washer or reconnect power.
6. Check drain pump.
7. Check the pressure switch.
8. Verify CCU operation by running a Diagnostic test or any cycle.






Kitchen Aid Front Loading Gas and Electric Dryer Fault Codes (Models KGHS01PMT/WH and KEHS01PMT/WH)
Failure CodeFault Code DescriptionSolution
PFPower failure“PF” flashes to indicate that a power failure occurred while the dryer was running. Press HOLD TO START to continue the cycle, or press OFF/Pause to clear the display.
E1Thermistor openReplace thermistor if found defective
E2Thermistor shortedReplace thermistor if found defective
E3User interface or software mismatchThis error code will ONLY appear when in the Diagnostic Test mode.

If the E3 error code is displayed, there is a user interface or software mismatch. It is also possible that a component on the console electronics or the electronic control board has failed. Replace defective component.






Kitchen Aid Pro Line Front Loading Automatic Washer Fault Codes (Model KHWV01RSS)
Failure CodeFault Code DescriptionSolution
FHNo water detected entering machine or pressure switch trip not detectedIf after 30 seconds the control does not detect water entering machine, the valves will be turned off and the error code will be displayed.
OR
If the control has turned the water valves on, and after 8 minutes, the flow sensor has detected 10.5 gallons of water passing through it, but has not detected the pressure switch trip, the valves will be turned off, and the error code will flash.
Press PAUSE/CANCEL twice to clear the display.

Possible Causes / Procedure

•  If there is no water in the unit:
– Make sure that both valves at the water source(s) are turned on all the way.
– Check for plugged or kinked inlet hoses or plugged screens in the inlet valves.
– Verify inlet valve operation. •  If there is water in the unit:
– Verify drain pump operation.
– Verify that the pressure switch hose is in good condition and properly connected to tub
and pressure switch. 1. Verify there is not a siphon problem.
2. Unplug washer or disconnect power.
3. Verify wire harness connections to inlet valves, pressure switch, drain pump, flow meter,
and Central Control Unit (CCU).
4. Check all hoses for possible leaks.
5. Plug in washer or reconnect power.
6. Verify pressure switch operation.
7. Verify flow meter operation by blowing air through the part and measuring the resistance.
8. Verify CCU operation by running a Diagnostic test or any cycle. Replace failed component.

F02Long drainIf the drain time exceeds eight minutes, the water valves are turned off and “F02” is flashed.

Press PAUSE/CANCEL two times to clear the display.

NOTE: After four minutes the “Sud” error will be displayed, then four minutes later the “F02” error code will be displayed..

Possible Causes / Procedure

1. Check the drain hose and make sure it is not plugged or kinked.
2. Unplug washer or disconnect power.
3. Check the electrical connections at the pump and make sure the pump is running.
4. Check the drain pump filter for foreign objects.
5. Plug in washer or reconnect power.
6. If the above does not correct the problem, go to step 7.
7. Unplug washer or disconnect power.
8. Replace the pump.


F05Water temperature sensor errorIf during the water heating step in the wash cycle, the water temperature sensor (NTC) value is out of range, the “F05” error code will be displayed.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check the water temperature sensor. Check connections to the water temperature sensor.
3. Check resistance of heating element, if present on this model. (abnormal = infinity).

Replace failed component.


F06Drive motor tachometer errorThe control is unable to properly detect motor speed and the machine will shut down. If a failure occurs during high-speed spin, the door will be unlocked after three minutes.

Possible Causes / Procedure

1. Verify the shipping system including shipping bolts, spacers and cables are removed.
2. Unplug washer or disconnect power.
3. Check wire harness connections between the drive motor and the Motor Control Unit (MCU), and between the MCU and the Central Control Unit (CCU).
4. Plug in washer or reconnect power.
5. Check the MCU by looking for operations of the drive motor.
6. Check the drive motor for powered rotations.

Replace failed component.


F07Motor control unit errorThe main control has detected a short in the Motor Control Unit. If a failure occurs during high-speed spin, the door will be unlocked after three minutes.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check wire harness connections between the drive motor and the Motor Control Unit (MCU), and between the MCU and the Central Control Unit (CCU).
3. Plug in washer or reconnect power.
4. Check the MCU by looking for operations of the drive motor.
5. Check the drive motor for powered rotations.

Replace failed component.


F09Overflow conditionIf the overflow contact on the pressure switch is closed for more than 60 seconds, an Overflow Condition will occur. In an overflow condition, the door remains locked and the drain pump runs constantly, even if PAUSE/CANCEL is pressed twice and the display is cleared. Turn off hot and cold water faucets and unplug the unit before servicing.

Possible Causes / Procedure

1. Check the drain hose and make sure it is not plugged or kinked.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the drain pump, pressure switch, and Central Control Unit (CCU).
4. Check/clean drain pump filter of foreign objects.
5. Check for drain pump failure.
6. Check the inlet valve for proper shut off.
7. Check the pressure switch for proper operation.

Replace failed component.


F10Motor control unit (MCU) heat sink thermal tripIf the thermal protector on the MCU heat sink gets too hot, it will open the thermal protector on the heat sink which will stop motor functions and an “F10” will be displayed.

Possible Causes / Procedure

1. Check for proper installation, verify the unit is not located near a source of heat and has proper ventilation.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the MCU, the motor, and Central Control Unit (CCU).
4. Check the drive system for any worn or failed components.
5. Plug in washer or reconnect power.
6. Check the MCU by looking for operations of the drive motor.
7. Check the drive motor for powered rotations.

Replace failed component.


F11Serial communication errorCommunication between the Central Control Unit (CCU) and the Motor Control Unit (MCU) cannot be sent correctly.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check wire harness connections to the MCU, the motor, and Central Control Unit (CCU).
3. Check the drive system for any worn or failed components.
4. Plug in washer or reconnect power.
5. Verify CCU operation by running a Diagnostic test or any cycle.
6. Check the MCU by looking for operations of the drive motor.
7. Check the drive motor for powered rotations.
8. Check that the serial harness at the MCU is not mounted upside down. The wires should be to the left when facing the MCU connectors.

Replace failed component.


F13Dispenser circuit errorIf the dispenser motor is not able to be driven to its proper position.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check mechanical linkage from dispenser motor to the top of the dispenser.
3. Check wire harness connections to the dispenser motor and Central Control Unit (CCU).
4. Check dispenser motor for powered rotations.

Replace failed component.


F14EEPROM errorThe Central Control Unit (CCU) receives its data from an EEPROM onboard the CCU. If there is an error reading this data it will cause this error.

Possible Causes / Procedure

A power glitch may cause this error.
1. Unplug washer or disconnect power for two minutes.
2. Verify CCU operation by running a Diagnostic test or any cycle. Replace if defective.


F15Motor control unit (MCU) errorIf the MCU detects multiple resets or errors during a wash cycle it will go into this error mode.

Possible Causes / Procedure

1. Unplug washer or disconnect power.
2. Check wire harness connections to the MCU, the motor, and Central Control Unit (CCU).
3. Check drive belt.
4. Plug in washer or reconnect power.
5. Check the MCU by looking for operations of the drive motor.
6. Check the drive motor for powered rotations.

Replace failed component.


F21
or
F22
CCU / Touchpad / LED assembly errorThis error occurs if the touchpad/LED assembly is not able to transmit/receive data to/from the central control unit (CCU).

Possible Causes / Procedure

1. Check the touchpad/LED assembly by selecting different cycles and changing the modifiers and options available to confirm the touchpad/LED is responding.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the touchpad/LED assembly and Central Control Unit (CCU).

Replace failed component.


F32Pressure switch failureIf after 30 seconds the control does not detect water entering machine, the valves will be turned off and the error code will be displayed.
OR
If the control has turned the water valves on, and after 8 minutes, the flow sensor has detected 10.5 gallons of water passing through it, but has not detected the pressure switch trip, the valves will be turned off, and the error code will flash. Press PAUSE/CANCEL twice to clear the display. Possible Causes / Procedure 1. Unplug washer or disconnect power.
2. Check to verify that the pressure switch is operational.
3. Replace pressure switch.

F33System leakIf after 30 seconds the control does not detect water entering machine, the valves will be turned off and the error code will be displayed.
OR
If the control has turned the water valves on, and after 8 minutes, the flow sensor has detected 10.5 gallons of water passing through it, but has not detected the pressure switch trip, the valves will be turned off, and the error code will flash. Press PAUSE/CANCEL twice to clear the display. Possible Causes / Procedure 1. Check for crack or holes in the washer tub and pressure switch hose.
2. Replace components if necessary.

FdUDoor unlock errorA Door Unlock Error occurs if the door cannot be unlocked. It will try to unlock the door six times before displaying the error code.

Possible Causes / Procedure

• Door lock mechanism is broken.
• Door switch/lock unit failure.
1. Check door switch/lock unit for foreign objects.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the door switch/lock unit and Central Control Unit (CCU).

NOTE: The door switch/lock unit can be manually unlocked:

To manually unlock the door lock system, perform the following steps.
1. Unplug the power cord from the outlet.
2. Remove the lower toe panel.
3. Reach up along the inside of the front panel and locate the bottom of the door latch assembly.
4. Located on the bottom of the door latch assembly is a teardrop shaped tab. Gently pull the tab down approximately 1/4 inch, or until a click is heard.
5. The door may now be manually opened.


FdLDoor lock errorA Door Lock Error occurs if the door cannot be locked. It will try to lock it six times before displaying the error code.

Possible Causes / Procedure

• Door lock mechanism is broken or removed from door.
• Door switch/lock unit failure.
1. Unplug washer or disconnect power.
2. Check door switch/lock unit.
3. Check the wire harness connections to the door switch/lock unit and Central Control Unit (CCU).


SudSuds lock (Overdose of detergent detected during the wash cycle)The Motor Control Unit senses a suds lock condition by analyzing the current draw on the drive motor. If “Sud” is displayed a potential Suds Lock is detected. This may signify a bad pump, an extra heavy load, excessive detergent, or excessive suds.

Possible Causes / Procedure

• If too much detergent was used:
– Run the unit through a Rinse/Spin cycle.
– Run a Normal cycle without adding any detergent.

This should clear the unit of the excess detergent.

1. Check the drain hose and make sure it is not plugged or kinked.
2. Unplug washer or disconnect power.
3. Check wire harness connections to the drain pump, pressure switch, and Central Control Unit (CCU).
4. Check/clean drain pump filter of foreign objects.
5. Plug in washer or reconnect power.
6. Check drain pump.
7. Check the pressure switch.
8. Verify CCU operation by running a Diagnostic test or any cycle.






Kitchen Aid Pro Line Front Loading Gas and Electric Dryer Fault Codes (Models KHEV01RSS and KHGV01RSS)
Failure CodeFault Code DescriptionSolution
PFPower failurePF flashes to indicate that a power failure occurred while the dryer was running. Press Start to continue the cycle, or press Pause/Cancel to clear the display.
E1Temperature sensor openE1 flashes in the numeric display when the temperature sensing circuit is open. Replace temperature sensor if faulty.
E2Temperature sensor shortedE2 flashes in the numeric display when the temperature sensing circuit is shorted. Replace temperature sensor if faulty.
E3Blower rotation failureIf during a cycle the blower rotational speed drops below 500 rpms, all outputs will be turned off and error code E3 will be displayed.
E4Tumbler rotation failureIf during a cycle the tumbler rotational speed drops to 0, all outputs will be turned off and error code E4 will be displayed.
E5Dry rack sensorIf during a Dry Rack cycle the signal is lost, all outputs are turned off and E5 is displayed.
E6Exhaust high limit faultIf the exhaust temperature goes above 87.7°C (190°F) all outputs will turn off and E6 will be displayed.



X

GET $25 OFF ANY REPAIR

Disclaimer: please make sure to unplug your appliance if you feel that it is malfunctioning. Consult with an Express Repair professional to prevent any further damage to your appliance.



KitchenAid  Dishwasher  Error Codes for HE Models

These error code explanations can help you diagnose a problem with your KitchenAid HE dishwasher.

Error CodeConditionCheck/Repair
1-1The electronic control board detects a stuck relay on its circuit board.Shut off power to the dishwasher for 5 minutes. If the code resumes when you restore power, have a service technician check the wiring and components. If the wiring and components are in working order, replace the electronic control board.
1-2Damaged or corrupted memory on control board. Incompatible software components inside microprocessor.Shut off power to the dishwasher for 5 minutes. If the code resumes when you restore power, replace the electronic control board.
2-1The electronic control board detected a stuck key on the control panel.See if any keys work. If no keys work or the control panel is damaged, replace the electronic control panel. If the control panel works, the problem might be with the electronic control board.
2-2The electronic control board detects no communication from the control panel.See if any keys work. If no keys work or the control panel is damaged, replace the electronic control panel. If the control panel works, the problem might be with the electronic control board.
3-1Either there’s a break in the wiring or the thermistor/OWI component failed. (The thermistor is the water temperature sensor, the OWI is the Optical Water Indicator that detects the amount of debris in the water.)Shut off power to the dishwasher and then check the wiring for the thermistor/OWI circuit. If the circuit wiring is undamaged, replace the thermistor/OWI component.
3-2The thermistor/OWI circuit is electrically shorted, (The thermistor is the water temperature sensor, the OWI is the Optical Water Indicator that detects the amount of debris in the water.)Shut off power to the dishwasher and then check the wiring for the thermistor/OWI circuit. If the circuit wiring is undamaged, replace the thermistor/OWI component.
3-3OWI fails (the OWI is the Optical Water Indicator that detects the amount of debris in the water)Shut off power to the dishwasher and clean the OWI. If the code resumes when you restore power, replace the OWI
4-4The electronic control board detects no circulation pump motor operationShut off power to the dishwasher. Check all wiring connections in the motor circuit. Reconnect any loose wires. Replace the wire harness if damaged. If the wiring connections are okay, replace the circulation pump motor.
5-1Door won’t latch shutPress the Start button and immediately close the door. If the code continues, shut off power to the dishwasher and check the door latch mechanism and the wiring attached to the door switch. If the latch mechanism and the wiring are intact, replace the door switch.
5-2Door won’t openCheck the wiring in the door switch. If the wiring is undamaged, replace the door switch.
6-1The electronic control board doesn’t detect water entering the dishwasher tub.Shut off power and then water to the dishwasher. Check the water supply for proper flow and pressure. Check the wiring to the water inlet valve. If the wiring and the water supply are in working order, replace the water inlet valve.
6-2Water inlet valve has an electrical problem.Shut off power and then water to the dishwasher. Check the water supply for proper flow and pressure. Check the wiring to the water inlet valve. If the wiring and the water supply are in working order, replace the water inlet valve. If the problem continues, replace the electronic control board.
6-3Suds or air are in the water pumpCheck the water fill level and check for suds in the fill water at the bottom of the tub. if the fill level is too low, replace the water inlet valve. If there’s excessive sudsing, check the detergent dispenser and replace if it’s damaged
6-4The float switch is openCheck the overfill float switch to see if it’s stuck or if an item is stuck under it. Check if the inlet water fill valve is properly shutting off the water supply when the dishwasher is off.
6-6Incoming water is too coldUse an accurate thermometer to check the water temperature. If it’s lower than 110 degrees F, check your water heater. water heater. If the water temperature is normal (110 to 120 degrees F), replace the thermistor/OWI or the electronic control board. Refer to the tech sheet for your dishwasher for a diagnostic test for the thermistor.
7-1Heating element doesn’t workShut off power to the dishwasher. Inspect the heating element and replace it if it’s visibly damaged. If not, check the wiring to the heating element. If the wiring is intact, replace the heating element.
7-2Heating element won’t shut offShut off power to the dishwasher for 5 minutes. If the code resumes when you restore power, replace the electronic control board.
8-1Slow drainShut off power to the dishwasher and then shut off water. Check the drain path for an obstruction. If the drain path is clear, check the wiring on the drain pump. If the wiring is intact, replace the drain pump.
8-2Drain pump electrical problemShut off power to the dishwasher and then shut off water. Check the wiring on the drain pump. If the wiring is intact, replace the drain pump.
9-1Electronic control board can’t detect the position of the diverterThe diverter directs the water through the lower spray arm or the upper spray arm. Turn off power to the dishwasher and then check the wiring going to the diverter motor. If the wiring is intact, replace the diverter.
9-2Diverter is stuck onRemove the lower dishrack and the lower spray arm. Disassemble the sump. Check the diverter disk and replace if visibly damaged.
9-3Diverter disk is missingRemove the lower dishrack and the lower spray arm. Disassemble the sump. Check to see if the diverter disk is missing. If the disc is missing, install a new disk.
9-4Lower spray arm errorCheck for obstructions blocking the lower spray arm from turning. Shut off power to the dishwasher and check the wiring connections on the lower spray arm motor. If the wiring is intact, replace the lower spray arm motor.
10-1Dispenser electrical problemShut off power to the dishwasher. Remove the outer door panel and check the wiring in the detergent dispenser circuit. If the wiring is intact, replace the detergent dispenser.
10-2Vent wax motor electrical problemShut off power to the dishwasher. Check the wiring in the vent wax motor circuit. If the wiring is intact, replace the vent wax motor.
10-3Drying fan problemShut off power to the dishwasher. Check the wiring in the drying fan circuit. If the wiring is intact, replace the drying fan.
Google Rating
4.1
$25 COUPON

X

GET $25 OFF ANY REPAIR

X

BOOK YOUR REPAIR
